· Nominal Input Level: -20 dBu
· Input Impedance: 1 M ohm
· Nominal Output Level: -20 dBu
· Output Impedance: 1 k ohm
· Recommended Load Impedance: 10 k ohm or greater
· Power Supply DC 9 V: Carbon-zinc battery (9 V, 6F22), Alkaline battery (9 V, 6LR61), AC Adaptor (optional)
· Current Draw: 45 mA (DC 9 V) * Expected battery life under continuous use: Carbon: 2 hours, Alkaline: 8 hours. These figures will vary depending on the actual conditions of use.
· Accessories: Owner’s Manual, Alkaline battery (9 V, 6LR61)
· Options: AC Adaptor (PSA series)
· Expression Pedal: EV-5 (Roland), FV-500L/FV-500H
